Description
The GSRM20B is a short scale Soundgear series solid body electric bass model introduced by Ibanez in 2015. It was made in both China and Indonesia as part of the entry level GIO; Indonesian production ended in 2022.
The GSRM20B features a double-cutaway mahogany body bolted to a 28.6″ scale maple neck with a 22-fret rosewood fingerboard with white dot position markers. Components include a pair of Ibanez Powersound pickups with a jazz pickup at the bridge and a precision pickup at the neck, a B10 bridge with 19mm string spacing, a plastic nut and Ibanez tuning machines.
-
SPECS
- neck type
- GSRM4Maple neck
- top/back/body
- Okoume body
- fretboard
- Bound Purpleheart fretboardWhite dot inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- B10 bridge
- string space
- 19mm
- neck pickup
- Dynamix P neck pickupPassive
- bridge pickup
- Dynamix J bridge pickupPassive
- factory tuning
- 1G,2D,3A,4E
- string gauge
- .045/.065/.085/.105
- hardware color
- Black
-
NECK DIMENSIONS
-
- Scale :
- 726mm/28.6″
- a : Width
- 38mm at NUT
- b : Width
- 58.5mm at 22F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 22mm at 12F
- Radius :
- 350mmR
Controlls
-
