Roland 80W Personal Monitor for V-Drums PM-100

Description

High-Resolution Sound Monitoring, Fine-Tuned for Roland’s V-Drums

Delivering rich, dynamic sound from a minimal footprint, the PM-100 is the ideal compact monitoring solution for Roland’s V-Drums. Equipped with 80 watts of power, the PM-100 features a custom full-range speaker system and rugged cabinet specially optimized for reproducing the famously expressive V-Drums sound and response. And with onboard mixing capabilities, you’re able to connect music players and other devices for practice and enjoyment while playing at home.

Pro-Level Sound for Playing V-Drums

The PM-100 is the perfect complement to any V-Drums set. Its compact size is ideal for playing at home, and the powerful custom speaker system delivers rich, full-range sound with inspiring punch and presence. The front face is angled for optimal sound monitoring while seated at the V-Drums, and a full-width bar handle on top offers a convenient way to carry the monitor and adjust its floor position.

Versatile Onboard Mixing

With its integrated mixer, the PM-100 allows you to monitor backing music and external devices along with your kit. There’s a dedicated V-Drums input, plus 1/4-inch and 1/8-inch line inputs for connecting electronic percussion pads, smartphones, and music players. Independent volume controls are provided for the V-Drums and line input sections, and there’s also a two-band equalizer for shaping the overall sound.

Specifications:

• Rated Power Output: 80 W
• Nominal Input Level:
  • V-Drums INPUT: -6 dBu (10 k ohms)
  • LINE INPUT: -6 dBu (10 k ohms)
• Speaker: 25 cm (10 inches) Woofer x 1, 5 cm (2 inches) Tweeter x 1
• Controls:
  • POWER switch
  • V-Drums VOLUME knob
  • LINE INPUT VOLUME knob
  • BASS knob
  • TREBLE knob
• Indicators: POWER
• Connectors:
  • V-Drums INPUT jack: Stereo 1/4-inch phone type
  • LINE INPUT jack: Stereo 1/4-inch phone type, Stereo miniature phone type
  • AC IN jack
• Power Consumption: 36 W
• Accessories:
  • Owner’s manual
  • Power cord
• Width: 388 mm (15-5/16 inches)
• Depth: 407 mm (16-1/16 inches)
• Height: 354 mm (13-15/16 inches)
• Weight: 13.5 kg (29 lbs 13 oz)
