Description
SPECIFICATION:
Power consumption: 300W
Input voltage: AC 90V-240V,50-60Hz
Working position: any safe working position
Working position temperature: -10-40deg
Light source: Osram 4in1 RGBW 40WX 7pcs
Lifetime: >600,000hours
CTO: 2500K-8000K, 8-class color temperatures adjustment
Electronic zoom range: 4.5 ° -36 °
Motor: Two speedy 3-phase motors for Pan/Tilt
Pan movement range: 540°
Tilt movement range: 270°
CONTROL
Display: LCD display
DMX Channel: 12/17 DMX channels
Control mode: Master /Slave synchronization, Stand-alone
mode and DMX512 control
CONSTRUCTION
DMX link: 3pin/5pin DMX in and out
Power link: Powercon In and out
Protection rate: IP20, for indoor use
Housing: heat-proof plastic module + hard metal,
black/silver/white color, optional
PHYSICAL
Dimension: 310*225*370mm
Net Weight: 9.5kgs
Gross Weight: 12.5kgs
Product Drawing
